Chapter 1� Getting started 1-2
Notice for use
To set up your monitor, please see the illustrations below�
Note:
Do not touch the screen of the monitor� The screen is made of glass and can be damaged by
rough handling or excessive pressure�
1
2
1�
Place your monitor with the screen face down on a soft flat surface.
2� Insert the base towards the stand until it locks in place�
3� Align the stand assembly bracket to the monitor�
Note:
To connect VESA mounting accessories, refer to “Wall Mounting (Optional)” on page 2-9�
Product overview
In this section, we will describe how to adjust the position of the monitor; how to set user controls;
how to use the cable lock slot�
Adjustment type
Tilt
Please see the illustration below for an example of the tilt range�
