Brake chamber clamp repositioning – SAF-HOLLAND XL-AM20006BM Brake and Service Chamber User Manual
Page 9
9
XL-AM20006BM-en-US · 2014-04-22 · Amendments and Errors Reserved · © SAF-HOLLAND, Inc., SAF-HOLLAND, HOLLAND, SAF,
and logos are trademarks of SAF-HOLLAND S.A., SAF-HOLLAND GmbH, and SAF-HOLLAND, Inc.
Figure 12
Figure 11
Figure 10
5. After loosening both clamp nuts, remove one clamp nut
and bolt in order to remove the clamp. The service side
housing can now be rotated. Adjust the mounting bolts
position relative to air ports. (Figure 10, 11 and 12).
Brake Chamber Clamp Repositioning
