78
MODEL 5081-T
SECTION 10.0
DIAGNOSIS AND TROUBLESHOOTING
10.3 DIAGNOSTIC MESSAGES
The Model 5081-T transmitter’s diagnostics constantly monitor the conductivity loop for possible problems. If an opera-
tional problem is encountered, check the display for a fault or error message. These are displayed in the
Temperature/Current output segment of the display. Note the message and refer to Table 10-2 for a description of possi-
ble problems that may have triggered the diagnostic message.
Message
Description
Action
Faults
U17:![9
Temperature is too low.
Check wiring or sensor/process temp.
Check RTD.
U17:!45
Temperature is too high.
Check wiring or sensor/process temp.
Check RTD.
;UG!2-5[
The RTD sense line fault limits have been exceeded
Check wiring or Check Program/Temp
for the sensor.
menu setting to verify the 100-3 or
100-4 sensor type connected.
/:>!2-5[
The CPU has failed during RAM or EEPROM
Recycle. If persistent contact the factory.
verification.
2-/U!2-5[
The transmitter has not been accurately factory calibrated.
Contact factory.
S97 2-5[
The PROM failed the check-sum test.
Contact factory.
/A/[1:@6S
A wrong value was detected during power-up.
Recycle the power.
Warnings
5P:VU!@6-SP
The compensated conductivity limit of 9999 ms/cm is
Verify the conductivity range setting.
exceeded.
9WHS!S-PJ1
The current range setting has been exceeded.
Verify the 4 and 20 mA settings in the
Program/output menu.
-G/!HSSQS
An analog to digital conversion error has occurred.
Recycle the power.
(This may come up normally while readings are
changing quickly)
Errors
/-[!1SS!or
A calibration error has occurred between the standard
Press RESET and repeat.
9IITHU!1SS
and process.
Check calibration standards and unit
configuration.
U<[9:1!1SS
The limit for T-2 in a two point calibration has been
Press RESET and repeat the
exceeded.
calibrate/temp. slope menu setting.
\"\!1SS
Sensor Zero limit has been exceeded
Press RESET and repeat the cali-
brate/sensor menu setting.
@M;5=1 1SS
An attempt to the write on the EEPROM has failed.
The jumper JP-1 on the CPU board
has been removed.
TABLE 10-2. Diagnostic Fault Messages.
