Board Layout
Chapter 3
Embedded and Industrial Computing
Connectors and Jumpers List
The tables below list the function of each of the board
jumpers and connectors by labels shown in the above
section. The next section in this chapter gives pin
definitions and instructions on setting jumpers.
Table 3.1 Connector List for VES-8X6
Labels Function Pin Definition Reference
Page
AUDIO1 Audio connector
ATX1 ATX1 Power connector P11
ATX2 ATX2 Power connector P11
CFAN1 CPU fan connector 1 P13
CFAN2 CPU fan connector 2 P13
CN1A COM Express connector A
CN1B COM Express connector B
COM1 Serial port 1 connector
DP1 Display port connector
FDC1 Floppy connector 1 P14
HDMI1 HDMI connector 1
J422/485 Serial Port 2 RS422/485 connector P11
JAT1 12V control selector P13
JAUDIO1 7.1ch Audio connector P12
JAUDIO2 Front Audio connector P12
JBAT1 Clear CMOS P14
JBKL1 LCD Inverter connector P14
JCD1 CD-ROM Audio Input connector P12
JCN3 MultI-purpose connector P15
JCOM2 Serial Port 2 RS232 connector P11
JDIO1 DIO connector P11
JFP1 Front panel connector P14
JFWH1 Firmware Hub BIOS chip select P15
JHDMI1 PCIE2 (DDI) signal selector P15
JIR1 IR connector P12
JLPC1 LPC port connector P13
JPCIE1 PCIE signal selector P15
JPRT1 Printer connector P13
JPWR1 S3 signal control selector P15
JRI1 COM1 pin 9 signal select P12
JSPDIF1 SPDIF connector P12
JSPI1 SPI Selector P15
JSPI2 Carrier board SPI FLASH programming P15
JUSB1 USB 4&5 connector P13
JVR1 LCD backlight brightness adjustment connector P15
KBMS1 KB/MS connector
LAN1/2 Ethernet connector
LVDS1 LVDS connector P13
MINI-PCIE1 PCI Express Mini Card slot
PCIE1 PCI Express x16 connector
PCIE2 Digital Display Interfaces (DDI) slot
PCIE3 PCI Express x4 connector
PCIE4 PCI Express x1 connector
RESET1 Reset button
SATA 1/2/3/4 Serial ATA connector
SDIO1 SD card slot
SFAN1 System fan connector P13
SIM1 SIM card slot
USB 0&1 USB connector 0&1
USB 2&3 USB connector 2&3
