21
Pr
ep
arations
E
Fastening the Grip Belt
Adjust the grip belt so that you can reach the
zoom lever with your index and middle finger,
and the start/stop button with your thumb.
Attaching the Shoulder Strap
Pass the ends through the strap mount and
adjust the length of the strap.
Be careful not to drop the camcorder when adjusting the strap or the grip belt.
Attaching the Adapter Holder
Attach the adapter holder to use the optional CH-910 Dual Battery Charger/Holder or a commercially
available wireless microphone receiver.
1. Attach the adapter holder and secure it by
tightening the screws.
2. Adjust the position of the support bars.
When using the optional CH-910, hook it onto the
support bars and secure it with the stop lever. To
detach the CH-910, press the stop lever in the
direction of the arrow and pull it off the support bars.
Stop lever
Support
bars
