Delfield T14D - Manual

Exterior: Cabinet exterior sides, front, door and grill
are corrosion resistant stainless steel.
Interior: Cabinet interior is corrosion resistant
stainless steel. Bottom and side corner surfaces are
stamped to provide radius corners and recessed floors.
Chrome plated pan racks accommodate up to
(26) 12” x 20” x 2 1/2” deep, or (13) 18” x 26” full size
pans. Pan lip rests in pan slide assembly. Pan slide
assembly is easily removable without the use of tools
for cleaning. Stainless steel evaporator housing is
mounted to the rear of the cabinet and removes for
cleaning or evaporator access without the use of tools.
Doors: Stainless steel exterior and stainless steel
interior door liner. Doors are field reversible with
predrilled hinge mounting holes on both sides of
the cabinet. Door seals tight to the cabinet with a
magnetic door gasket. Gaskets snap into place and is
easily removable without the use of tools.
Specifications
Standard Features
• Blast chill cycle: 154lb. chilling capacity - from
200˚F to 38˚ F in approximately 90 minutes
• Shock freeze cycle: 120lb. freezing capacity -
from 200˚F to 0˚F in approximately 240 minutes
• On board, integral printer - date, temperatures
and times during all chilling cycles printed out
• Automatic hot gas defrost
• Electronic control with 99 program capability
and HACCP memory
• Time chill or temperature chill
• 1 core temperature probe
• Stainless steel interior and exterior
• Soft chill cycle for delicate foods
• Self-contained condensing unit
• Standard 1 year parts and labor, 5 year
compressor warranty
Options &
Accessories
• Casters
• Trolley guide for use with 6.20 or
10.10 ConvoTherm rack
Companion piece to the following products. Model
T14D Blast Chiller/Shock Freezer
T14D Blast Chiller/Shock Freezer
T1
4D
: B
las
t C
hil
le
r/S
ho
ck
Fr
ee
ze
r
Project_ __________________________________
Item______________________________________
Quantity__________________________________
CSI_Section_11400
Approved_________________________________
Date_ ____________________________________
980 S. Isabella Rd.
Mt. Pleasant, MI 48858 Phone: 800-733-8948
Fax: 800-669-0619
www.delfield.com
Delfield
™
®
LÞ
Refrigeration system: Evaporator and condensing
unit are self-contained and standard with the unit.
Condensing unit is mounted at the bottom of the
cabinet. The evaporator is mounted to the rear of
the cabinet interior. Environmentally friendly R404A
refrigerant is used. System has the capability of
chilling up to 154lbs. of product from 200˚F to 38˚F in
approximately 90 minutes or freezing up to 120lbs. of
product from 200˚F to 8˚F in approximately 240 minutes.
Two fans mounted to the front of the evaporator moves
air at velocity sufficient to assure rapid, even cooling.
System is controlled by an electronic microprocessor
control designed for easy operation. Unit is designed
to chill or freeze either for a designated time period,
programed by the user or by temperature as monitored
by a probe placed in the food product. One temperature
probe is supplied. Operator has the choice of using a
soft chill cycle for chilling delicate product or a hard
chill cycle for denser, less delicate product. Evaporator
defrost is automatic using a time/temperature
terminated system. User also has the option of initiating
a defrost cycle manually. Evaporator condensate is
eliminated using an energy efficient hot gas system.
Electrical: Standard electrical connections are 220-
230/60/3. Connection must be hard wired to a junction
box.
OES 6.20
OEB 6.20
OGS 6.20
OGB 6.20 OES 10.10
OEB 10.10
OGS 10.10
OGB 10.10 OES 10.20
OEB 10.20
OGS 10.20
OGB 10.20
