Delfield ST4532N - Manual

Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
www.delfield.com
Exterior top is one-piece, 22-gauge stainless steel with integral
2.12” (5.4cm) square nosing on the front. The backsplash is full
width and 4” (10cm) tall.
Exterior back and bottom are two-piece 24-gauge galvanized
steel. Exterior ends are stainless steel.
Interior sides are thermoformed ABS plastic with shelves
supported on plugs. Interior back is one-piece 22-gauge
stainless steel. Interior bottoms are thermofoamed ABS
plastic. Base is fully insulated with high-density foamed in
place environmentally friendly, Kyoto Protocol Compliant, Non
ODP (Ozone Depletion Potential), Non GWP (Global Warming
Potential) polyurethane.
Refrigeration system uses HFC-404A refrigerant. Compressor,
condenser coil and hot gas condensate evaporator are mounted
on rear of the cabinet. Evaporator coil is located on the interior
rear wall of the cabinet. Refrigerant flow is controlled by a TXV.
Cabinet maintains an interior cabinet temperature of -5°F to
0°F (-21°C to -18°C).
Electronic control is located on the exterior back of the
cabinet. It allows the unit to maintain consistent temperatures
in heavy duty conditions.
Electrical connection is 115 volt, 60 Hertz, single phase. Unit
has a 6’ (1.8m) long electrical cord and NEMA 5-15P plug.
Casters: Equipment is mounted on 5” (13cm) diameter plate
casters with front two locking. Equipment clearance above the
floor is 2.5” (6cm).
Door has a 24-gauge stainless steel exterior, with thermoformed
ABS plastic interior liner.
Drawers have 24-gauge stainless steel exterior with
thermoformed ABS plastic interior liner. Drawer frames are
12-gauge stainless steel. Drawer slides are 11-gauge stainless
steel with Delrin bearings. Top drawer holds two full size 12”
x 20” (30.5cm x 50.8cm), 4”-6" x (10.2cm-15.2cm) deep pans.
Bottom drawer holds two full size 12 x 20", 4" deep pans. Pans
are supplied by others.
Specifications
Standard Features
Options &
Accessories
• 100% front breathing, which allows the unit to
be pushed against a wall or built into a cabinet
or an existing line up
• Durable, rugged stainless steel sides, top and
front
• Features Delfield’s exclusive ABS interior (on
sides). ABS is extremely durable - it won’t dent,
chip or corrode and is backed by a limited
lifetime warranty
• Heavy duty self-closing hinges
• “ST” prefix models have a 4” stainless steel
backsplash
• “D” prefix models feature Delfield’s exclusive
new drawer system. Drawers are backed by a
10-year warranty on the track assembly
• Environmentally friendly R404A refrigerant
• High density foamed in place environmentally
friendly, Kyoto Protocol Compliant, Non ODP
(Ozone Depletion Potential), Non GWP (Global
Warming Potential) polyurethane keeps energy
costs low
• Black recessed quick grip handle
• Standard on 5” casters for easy cleaning and
installation
• ST4532N Single section freezer with doors
• STD4532N Single section freezer with drawers
Models
ST4532N Flat Top
Front-Breathing Self-Contained Flat Top Freezer Bases
ST4532N F
lat
Top: F
ront
-Br
eathing S
elf-
Contained F
lat
Top F
reez
er Bases
• 60-cycle single phase electrical
system
• 6’ cord and plug supplied
• One epoxy coated wire shelf standard,
installed per door section
• Electronic control
• Three year parts and labor warranty
and an additional two year compressor
parts warranty
• 18” wide single tier overshelf
• Stainless steel finish on back
• Plastic laminate on front
• Additional wire shelves
• 3” casters, 3.75” ride height
• Door lock (solid door models only)
• Exterior thermometer (solid door
models only)
• Interior lights
• 220V/50 Hertz electrical system*
* Inclusion of this option will alter
electrical specifications of the unit
ST4532N
