- 118 -

PS-8810

DIGITAL SIGNAL PROCESSOR

100VAC to 240VAC, 24W nominal

If communication is lost, the unit will continue to function with the
last commands received

Selectable to 19.2K, 38.4K, 57.6K, or 115.2K BAUD
Serial, binary, asynchronous; 1 start bit; 1 stop bit; 8 data bits; no
parity
38.4 K BAUD
Serial, binary, asynchronous; 1 start bit; 1 stop bit; 8 data bits; no
parity

Optically isolated 20mA current loop
Half-duplex
Variable from 200 to 3000 feet (61 to 914 meters)., depending
upon wire capacitance. Typically 1000 feet (305 meters) using
shielded twisted-pair wire, #26 AWG or larger. Can be extended
with an IQ Repeater

+24VDC at 10mA
+20 dBu to -12dBu (additional 25 dB for mic setting)
24 bit, 48kHz
20kOhms balanced, 10kohms unbalanced
Greater than 100dB (A-weighted, 20 Hz-20KHz)
20Hz-20kHz, ± 0.5dB

50dB (typical)
Greater than 80dB at 10kHz

Less than 0.05% THD + N (1kHz, 0dBu)
100 Ohms balanced, 50 Ohms unbalanced
+32dBu (line) or +7dBu (mic)
+20dBu

Specifications

Audio:

Phantom power voltage:

Input Gain Range:

Digital Sampling:

Input Impedance:

Dynamic Range:

Frequency Response:

Common Mode

Rejection:

Crosstalk:

Total Harmonic

Distortion:

Output Impedance:

Max Input Level:

Max Output Level:

IQ Loop Data Communication:

IQ Loop Interface Type:

Operation:

Transmission Distance:

RS232 Data Communication:

Baud Rate:

Data Format:

Data Rate:

Data Format:

Power Requirements:

Protection:
