Analog Way DI-VENTIX II - Ref. DVX8044 Programmer's Guide - Manual (Page 28)

28
PE_OPENING_TRANSITION_WAY oW oW
opening transition
direction
Rd/Wr 0 3 0
0 = Left to right Transition
1 = Right to left Transition
2 = Bottom to top Transition
3 = Top to bottom Transition
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized
Preset 1
4 = Memorized
Preset 2
5 = Memorized
Preset 3
6 = Memorized
Preset 4
0 = Background
Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
PE_OPENING_DURATION oD oD opening transition time Rd/Wr 0 255 10
in 1/10 second (ex : 105 =
10.5s)
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized
Preset 1
4 = Memorized
Preset 2
5 = Memorized
Preset 3
6 = Memorized
Preset 4
0 = Background
Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
PE_CLOSING_TRANSITION cT cT layer closing transition Rd/Wr 0 2 1
0 = Cut Transition
1 = Fade Transition
2 = Slide Transition
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized
Preset 1
4 = Memorized
Preset 2
5 = Memorized
Preset 3
6 = Memorized
Preset 4
0 = Background
Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
PE_CLOSING_TRANSITION_WAY cW cW
closing transition
direction
Rd/Wr 0 3 1
0 = Left to right Transition
1 = Right to left Transition
2 = Bottom to top Transition
3 = Top to bottom Transition
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized
Preset 1
4 = Memorized
Preset 2
5 = Memorized
Preset 3
6 = Memorized
Preset 4
0 = Background
Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
