PE_POS_H
pH pH
layer left H position on
output screen
Rd/Wr 0
65535 32768
in pixel with 32768 offset
(32768 = left side, visible)
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized
Preset 1
4 = Memorized
Preset 2
5 = Memorized
Preset 3
6 = Memorized
Preset 4
0 = Background
Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
PE_POS_V
pV
pV
layer top V position on
output screen
Rd/Wr 0
65535 32768
in pixel with 32768 offset
(32768 = top side, visible)
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized
Preset 1
4 = Memorized
Preset 2
5 = Memorized
Preset 3
6 = Memorized
Preset 4
0 = Background
Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
PE_SIZE_H
pW pW
layer H size on output
screen (without borders)
Rd/Wr 0
65535 32768
in pixel
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized
Preset 1
4 = Memorized
Preset 2
5 = Memorized
Preset 3
6 = Memorized
Preset 4
0 = Background
Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
PE_SIZE_V
pS
pS
layer V size on output
screen (without borders)
Rd/Wr 0
65535 32768
in pixel
0 = Current Preset
1 = Next Preset
2 = Previous Preset
3 = Memorized
Preset 1
4 = Memorized
Preset 2
5 = Memorized
Preset 3
6 = Memorized
Preset 4
0 = Background
Frame
1 = Layer A
2 = Layer B
3 = Layer C
4 = Layer D
5 = Logo A
6 = Logo B
7 = Frame Mask
