Page 12

REPLACEMENT OF PARTS

REPLACING THE WlCK

USE ONLY GENUINE TOYOTOMI ”KS-27A” REPLACEMENT WlCK. SUBSTITUTE WICKS CAN SEVERELY

REDUCE PERFORMANCE AND SAFETY.

1. Release the automatic extinguisher by pushing the manual shutoff down.

2. Remove the three (3) screws and lift cover off.

3. Remove the three (3) wing nuts around the wick adjuster. Lift the wick adjuster

off the heater while moving it slightly back and forth.

4. Slide two fingers between the orange band on the wick and the silver wick

sleeve attached to the wick adjuster. Lift the pins in the wick off the slots in the

wick sleeve. After lifting all three (3) pins off the slots, fold the wick and

remove it. Leave the wick sleeve in place.

WARNING: Before disassembling your heater, allow it to cool completely.
