Pinnacle Systems STTS - Manual (Page 8)

2
TECHNICAL SPECIFICATIONS (Metal box controller)
Power: 18 - 28VDC @ 18 Watts Optional, requires removal of transformer.
(3 zones) 85-125VAC @ 19 VA All AC voltages work with 50 or 60 Hz
200-245VAC @ 19 VA Jumper change required
Max # of Mats: Up to 8 separate mat inputs
Total Response
Time: 35 mSec/mat input
Outputs:
Safety
: 2 N.O. outputs (open when RED) per zone 8A@250vac resistive
Auxiliary
: 1 N.O. or N.C. output per zone 8A@250vac resistive
Fault:
1 N.O. (open when faulted) 5A@250vac resistive
NOTE: Relay current rating is de-rated by ½ for inductive loads and again
by ½ for temperatures approaching 50C
Zone Reset
Inputs: 3 inputs for N.O. push-buttons for manual resetting of each zone (Green buttons
on front panel). J11 and J12 located on computer board (either one can be used
for remote resetting)
Settings: Jumpers to select manual or automatic reset, # of mats / zones and how many
zones, fault reset, and external relay checking. (S1, S5 and JP6)
Indicators:
Internal: Red LED on power supply board ON = +12V supply ok
Green LEDs on computer board 5v and 20V supply ok
External: 8 Yellow LED's (1 per mat input) Yellow LED on = standing on mat
Yellow LED flashing = Fault with
mat/circuitry
3 Red/Green LED’s (1 set per Green LED on = Relays energized
zone) on panel door Red LED on = Relays de-energized
Red LED flashing = Relay fault
DESCRIPTION DIMENSIONS MOUNTING HOLE
Computer board 6.50" x 8.00"
165.1 x 203.2 mm 6.00" x 7.50"
152.4 x 190.5 mm
Power supply board 6.50" x 8.00"
165.1 x 20,32 mm 6.00" x 7.50"
152.4 x 190.5 mm
Display board 4.00" x 5.75"
101.6 x 14,60 mm 3.50" x 5.00"
88.9 x 127.0 mm
Mounting plate
(used for short stack only) 8.87" x 8.87"
225.4 x 22,54 mm 8.00" x 8.00"
203.2 x 203.2 mm
Control Box 10.00"H x 9.00"W x 5.25"D
254H x 228.6W x 133.3D mm 7.75" x 10.75"
196.8 x 273.0 mm
Tolerance: +- 0.10 inches / 02.5 cm
Environmental: 0 to 50C
