Parr Instrument Series 4550 - Manual (Page 27)

4550 Floor Stand Reactors
w w w . p a r r i n s t . c o m 27
SUPPORT
BOTTOM ENCLOSURE
COUPLING
SUPPORT ROD
2481HC2
REAR PANEL
2704HC
SN7516HX HEX NUT
2705HC LIFT NUT
A2265HC2
2455HC
SPLIT RING ASSY
BELT GUARD
UPPER BACKPLATE
1/2 HP MOTOR
2566HC2
BUSHING
799DD
UPPER ENCASEMENT
2350HC9
LOWER BACKPLATE
2565HC2
MIDPLATE
2745HC
X2173
MAG DRIVE SHIELD
LEVELING SCREWS
BRACKET
2757HC
2407HC2
2756HC
2 GAL FIXED HEAD
VESSEL ASSEMBLY
A3170HC3
HINGED SPLIT
(4) SB2528SC08 SCREW
(4) SW25NL WASHER
2474HC
THREADED PIVOT
(2) 2394HC SPACER
(4) 2408HC
LEVELING SCREW
A2760HC4
PNEUMATIC LIFT PKG
RELEASE KNOB
LOWER CYLINDER
SUPPORT
SLEEVE BEARING
2407HC2
2352HC
2708HC
(2) 2482HC2
LIFT BLOCK
2707HC
726HC
DRIVE SHAFT ASSY
A2564HC2
LIFT BLOCK
CYLINDER MOUNTING
2709HC
CONTROLLER MOUNT
2553HC
QUICK CLOSE
A2755HC
BASE ASSEMBLY
UPPER CYLINDER
(3) 2408HC
2703HC
SLEEVE BEARING
4554
SUPPORT ROD
(2) 2706HC11 LIFT BRACKET
RING PKG
(NOT SHOWN)
A2275HC3
SPLIT RING ASSY
(SHOWN)
2444HC
RETAINER PLATE
(2) SB2528FT08
1/4-28 X .50 FHSCS
4554 - 2 Gallon Fixed Head Stand Assembly
