Lingenfelter LTCC - Manual (Page 10)

Tuning
There are two dials inside the unit
• LIM is the rev limiter
• RET is the N.O.S. Retard & Low Rev Limit
The settings are as follows:
Setting Result
0 Disabled
1 6100
2 6200
3 6300
4 6400
5 6500
6 6600
7 6700
8 6800
9 6900
A 7000
B 7100
C 7200
D 7300
E 7400
F 7500
Setting Retard – above 2000 RPM Low Rev
Limiter
0 None Disable
1 2 2600
2 4 2700
3 6 2800
4 8 2900
5 10 3000
6 12 3100
7 14 3200
8 16 3300
9 .5º per 1000 rpm 3400
A .75º per 1000 rpm 3500
B 1.5º per 1000 rpm 3600
C 2º per 1000 rpm 3700
D 2.5º per 1000 rpm 3800
E 3º per 1000 rpm 3900
F 12º – active at 1500 rpm for turbo brake torque. 4000
The Soft-Touch Rev Limiter Spans about 400 rpm. If set to 3000, it may climb as high
as 3400 until all cylinders are disabled. This can be altered if required.
