American Energy Systems MagnuM 7500 - Manual (Page 42)

42
ORDER # DESCRIPTION
AFP24 Spring Handle, Gold, Heat Exchanger Rod
CF02 Ash Pan Assembly, MagnuM 7500
CF06 Firepot, Stainless Steel, Corn/Biomass, 7500
CF13 Door, Black, 6500 & 7500, Countryside (when purchased separate from unit)
CF22 Filter, Cold Air Return, MagnuM 6500 & 7500
CF23 Fan Limit Control, MagnuM 7500 furnace 2004 or earlier, 2E232 (control only, wiring harness sold separate)
CF25 Blower/Fan, Room, Complete Assembly (when purchased separate from unit)
CF26 Motor, Auger Feed Gear, 8 rpm (MagnuM 7500 only)
CF27 Combustion Enhancement System
CF33 Motor, Furnace Blower, ¼ hp single speed (3M393) 2004 and older MagnuM 7500 (formerly part CF24)
CF35 Mount, Motor, New Auger Motor, Retro-Fit Kit (7500 furnace 2003 or earlier) not for new units
CF37 Scraper Assembly, Firepot, 6500
CF38 Firepot, Steel Corn/Biomass, 6500
CF40 Ash Pan Assembly, MagnuM 6500
CF3515 Door, 24K Gold, 6500, & 7500, Countryside (when purchased separate from unit)
CF3519 Door, Nickel, 6500 & 7500, Countryside (when purchased separate from unit)
MF3650 Draft/Exhaust, 2-speed Output Blowers, MagnuM 6500
MF3511 Bushing, Bronze (fuel stirrer shaft bearing) 2 pcs. (7500 & all countryside models)
MF3513S Fuel Stirrer, Welded, Stainless Steel, 7500
MF3514
Drive Shaft Assembly, Fuel Stirrer, 7500 (includes P003088 ½” ID collar)
MF3516 Chain, Fuel Stirrer, 7500
MF3517 Sprocket, Fuel Stirrer, 11-tooth sprocket on motor, 3/8” Diameter shaft, 7500
MF3518 Sprocket, Fuel Stirrer, 11-tooth sprocket on shaft, ½” Diameter shaft, 7500)
MF3521 Scraper Assembly, Firepot, 7500 (all product models except 6500)
MF3523 Door Handle Assembly 7500, 6500, all Countryside models
MF3526 Shoulder Bolt, with nut, ¼-20, Door Latch
MF3527 Hinge, Door (each) takes two (2) per unit
MF3530 Auger, 1 ½” Corn/ Wood Pellet/ Biomass, 7500 (3500P, 3500L, 3502 models)
MF3531 Glass, Door (all models of Countryside & 7500, 6500 Corn Furnace)
MF3532F Cord, Power, 7500 & 6500 furnace
MF3537 Safety Sensor, Low limit/Fan, 110 deg. (located on Exhaust Manifold & upper air shell, left side)
MF3540 Motor, Fuel Stirrer, MagnuM 7500 & all MagnuM Countryside models
MF3573 Motor, Auger Feed Gear, 4+ rpm (MagnuM 6500) Also used on MagnuM Countryside models
MF3592 Thermostat, Millivolt
MF3593 Control Board, MagnuM 7500 (current board used on Countryside)
MF3594 Control Board, MagnuM 6500
MF3610 Gasket, Exhaust Draft Motor (all models)
P6006 Auger, 2” Corn/Wood Pellet / Biomass, 6500
P7541 Rod, Heat Exchanger, MagnuM 7500
P7554 Brick board, 6500 & 7500B
P003015 Slides, Clean Out, left or right front, MagnuM 7500
P003053 Screw, Hex, #8 x ½” Tek ¼”
P003054 Screw, Phillips, #10-32 x 3/8”
P003073 Door, Clean-out, left or right lower back corners on MagnuM 7500 Furnace
R-116NKL Spring Handle, Nickel, Heat Exchanger Rod (when using Nickel plated door)
R0117 Plug, Clean-out, 1 1/2” diameter knockout plug
RP2050 Thermostat, Hi-Temp, Manual Reset, 225 Deg. 7500 & 6500
AMERICAN ENERGY SYSTEMS, INC.- Order placement: e-mail: [email protected]
Fax 320-587-8872 or call (800) 495-3196 Technical Support Call (320) 234-0743
