PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
" * ": Optional.
When ordering parts, be sure to quote the model number and part numbers.
9*
10*
11*
12*
13*
14*
15*
16*
17*
18*
REF. NO. DESCRIPTION QTY. SPARE PART NO.
2
2
2
2
1
1
2
2
PLUNGER VALVE (#10, #11 & #17 INCLUDED)
HOSE O-RING
STEP WASHER
STRAINER NUT
FLAT STRAINER RUBBER WASHER
THREADED STRAINER CONNECTOR
ADJUSTABLE POOL INLET NOZZLE
STRAINER GRID
VACUUM RELEASE VALVE
VACUUM RELEASE VALVE CAP (NOT SHOWN)
10747E
10262
10745
10256
10255
10744
11074
10253
11437
11576
9
10
11 12 13 14 15
9
10
11 12 13 14
16
17
17
*
*
