SECTIONS INTERNAL VIEWS
CW Sidetone
VR10
'Beeper" VR6
IF Unit (X48-1370-00)
Switch unit
(X41-1470-00) S
Top View
S-Meter
S-9 VR3
S-Meter
Zero VR2
■Filter Unit
(X51-1290-00)
■Final Unit
(X45-1 280-00)
Optional FM-430 mounting Space
Bottom View
Encoder unit
(X54-1 710-00)
RF Unit (X44-1 510-00/11
VFO Dial Drag ADJ.^
PLLUnit (X50-1910-00)
