Appendix A - Technical Specifications
O
O
Op
p
pt
t
ti
i
ic
c
ca
a
al
l
l S
S
Sp
p
pe
e
ec
c
ci
i
if
f
fi
i
ic
c
ca
a
at
t
ti
i
io
o
on
n
n
Design
Maksutov-Cassegrain Catadioptric
Aperture
4 inches (102mm)
Focal Length
52 inches (1325mm)
F/ratio of the Optical System
13
Primary Mirror:
Diameter
Coatings
102mm
Multi-layer coating process
Secondary Mirror Spot Size
Secondary Obstruction
1.25"
34.4% by diameter; 11% by area
Corrector Plate:
Material
Coatings
BK-7 Optical Glass
A-R Coatings both sides
Highest Useful Magnification
240x ( ~ 6mm eyepiece)
Lowest Useful Magnification (7mm exit pupil)
15x
( ~ 80mm eyepiece)
Resolution: Rayleigh Criterion
Dawes Limit
1.36 arc seconds
1.14 arc seconds
Photographic Resolution
140 lines/mm
Light Gathering Power
212x unaided eye
Near Focus standard eyepiece or camera
~ 20 feet
Field of View: Standard Eyepiece
: 35mm Camera
1.0º
1.51º x 1.04º
Linear Field of View (at 1000 yds)
52.5 feet
Magnification: Standard Eyepiece
: Camera
53x
27x
Optical Tube Length
13.5 inches
Weight of Telescope
11 Lbs.
E
E
El
l
le
e
ec
c
ct
t
tr
r
ro
o
on
n
ni
i
ic
c
c S
S
Sp
p
pe
e
ec
c
ci
i
if
f
fi
i
ic
c
ca
a
at
t
ti
i
io
o
on
n
ns
s
s
Input Voltage
Maximum
Minimum
12 V DC Nominal
18 V DC Max.
8 V DC Min.
Batteries Required
8 AA Alkaline
Power Supply Requirements
12 VDC-750 mA (Tip positive)
M
M
Me
e
ec
c
ch
h
ha
a
an
n
ni
i
ic
c
ca
a
al
l
l S
S
Sp
p
pe
e
ec
c
ci
i
if
f
fi
i
ic
c
ca
a
at
t
ti
i
io
o
on
n
ns
s
s
Motor: Type
Resolution
DC Servo motors with encoders, both axes
.26 arc sec
Slew speeds
Nine slew speeds: 4º /sec, 2º /sec, 1º/sec, .5/sec, 32x, 16x, 8x, 4x, 2x
Hand Control
Double line, 16 character Liquid Crystal Display
19 fiber optic backlit LED buttons
Fork Arm
Cast aluminum, with integrated hand control receptacle
S
S
So
o
of
f
ft
t
tw
w
wa
a
ar
r
re
e
e S
S
Sp
p
pe
e
ec
c
ci
i
if
f
fi
i
ic
c
ca
a
at
t
ti
i
io
o
on
n
ns
s
s
Software Precision
16 bit, 20 arc sec. calculations
Ports
RS-232 communication port on hand control
Tracking Rates
Sidereal, Solar, Lunar and King
Tracking Modes
Alt-Az, EQ North & EQ South
Alignment Procedures
AutoAlign (2-star alignment)
Database
25 user defined programmable object.
Enhanced information on over 100 objects
Total Object Database
4,033
