All pictures, descriptions, and specifications found in this
instruction manual are subject to change without notice.
AquaCraft maintains no responsibility for inadvertent errors
in this manual.
Below is a list of items that are generally required to run a
non-pullstart nitro boat. You will want to consult your
engine’s manual for any special items or brands that they
might recommend.
❏
Hot Shot ™ 2 Glow starter (HCAP2520)
❏
Torqmaster ™ 90 Starter (HCAP3200)
❏
Torqmaster 12V 7A Battery (HCAP0800)
❏
12V Charger (HCAP0200)
❏
Hand-Crank Fuel Pump (HCAP3015)
❏
Nitromethane model boat fuel such as O’Donnell 30%
boat racing fuel (DTXP0432, Consult your engine
manual for specific requirements)
❏
#2 Phillips screwdriver (HCAR1024)
❏
Hobbico ® Heavy-Duty diagonal cutter 7" (HCAR0627)
❏
Metric (HCAR1190) and standard hex drivers (HCAR1195)
❏
Adjustable wrench
❏
Pliers (HCAR0625)
❏
Flex cable grease (HCAB3000)
❏
After Run Engine Oil (HCAP3000)
❏
Glow plugs (consult your engine manual for specific
requirements)
❏
Fuel tubing (GPMQ4131)
❏
Hook & Loop material (GPMQ4480)
❏
Hobby knife (HCAR0109)
❏
Cable ties (BUKC2475)
❏
Extra “AA” batteries (EVEP1202 – 4 pk, FUGP7316 – 16 pk)
❏
Thread-locking compound (DTXR2010)
❏
Great Planes ® Pro ™ CA glue (medium – GPMR6009,
debonder – GPMR6039)
❏
Paper towels
❏
Spray-on glass cleaner
❏
Sunglasses
❏
Sun block
❏
Waders or rubber boots
❏
Cooler with plenty of ice and soda
❏
Folding table
❏
Lawn chairs
❏
First aid kit
❏
EZ-up or canopy for shelter
❏
4 or 5-cell Receiver pack (DTXM2010)
❏
O.S. ® .21 XM Engine (OSMG1721)
❏
Futaba ® 2PL 2-channel radio (FUTK01**)
❏
Drill bits: 1/8" [3mm], 13/64" [5mm] (or 7/32" [5.5mm]),
15/64" [6mm], and 13/32" [10.5mm]
❏
Phillips head screwdriver (HCAR1022)
❏
Needle-nose pliers (HCAR0625)
❏
Adjustable wrench (for changing propellers)
Optional Tools:
❏
Ultimate Body Reamer (DTXR1157)
BOW: The front of the boat
STERN: The back of the boat
PORT: This is the left side of the boat when aboard and
facing the front (bow). An easy way to remember this is that
both port and left contain four letters.
STARBOARD: This is the right side of the boat when
aboard and facing the front (bow).
HULL: The body of the boat.
DECK: The top of the boat
SPONSON: The projections at either side of hull that give
lateral stability on the water.
HOOKING: The effect caused when one of the sponsons
digs into the water and violently spins the rear of the boat
around. This usually stalls the engine.
Do not use too much force when tightening self-tapping
screws. Overtightening will cause the threads in the material
to strip. We recommend that you stop turning a self-tapping
screw once you feel some resistance as the head of the
screw comes in contact with the material. Avoid using
powered screwdrivers when assembling this kit. They tend
to overtighten the screws. Do not use thread-locking
SCREW INFORMATION
BOAT TERMINOLOGY
ITEMS REQUIRED TO COMPLETE ASSEMBLY
OTHER USEFUL ITEMS TO HAVE ON HAND
USEFUL TOOLBOX ITEMS
SUGGESTED FIELD EQUIPMENT
SPECIFICATION & DESCRIPTION CHANGES
If the buyer is not prepared to accept the liability
associated with the use of this product, the buyer is
advised to return this kit immediately in new and
unused condition to the place of purchase.
