2. Slide off the battery door on the bottom of the
transmitter. Install 8 fresh “AA” batteries into the bottom of the
transmitter in the configuration molded into the battery holder.
Re-install the battery door onto the bottom of the transmitter.
❏
3. Turn the transmitter “ON” using the switch on the front.
The red LED light next to the on/off switch should light up. If
the LED begins flashing erratically, turn the transmitter off and
check to make sure that the batteries are installed properly.
If you see a steadily flashing LED, the batteries are low and
need to be replaced.
BATTERY PACK CHARGING & INSTALLATION SEQUENCE
• IMPORTANT! The included charger unit is designed for
use in an automobile’s 12-volt power outlet.
• Do not attempt to charge a battery pack while the
automobile is running.
• The charger is equipped with a 70” charging lead. It is
highly recommended that the charger be placed outside
of the vehicle while in use.
• NEVER LEAVE A CHARGER AND BATTERY PACK
UNATTENDED WHILE CHARGING.
• Use only the battery pack and charger intended for use
with the Reef Racer 2. In the event that you use a
different battery charger, charge this pack at a maximum
charge rate of 1.2 amps.
• Charge the battery pack only after it has been
fully discharged.
❏
1. Plug the battery charger into an automobile’s 12-volt
power outlet as shown.
❏
2. Join the battery and charger connectors as shown. Do
not force them together; they are designed to fit together only
one way.
❏
3. Set the charger’s timer to 30 minutes. The red LED on
the charger will illuminate to indicate that charging is in
progress. It is a good idea to check the battery pack every five
(5) minutes. If at any time the battery pack becomes very hot
during the charging process, immediately unplug the charger
from the outlet and allow the battery to cool completely
before attempting to use.
❏
4. After charging is completed, unplug the charger unit
from the outlet. Disconnect the battery and charger
connectors by pushing the small tab down while gently
pulling the connectors apart.
Antenna
Power
Light
On/Off
Throttle
Steering
Trim
Steering
Wheel
