Seite 5
TABLET PRESS
1.2.2 Pressing tool set up
1.2.3 Toolkit
1.2.4 Fields of application
Manual hydraulic Pellet Press for the preparation of solid samples for X-ray
fluorescence analysis or infrared spectroscopy for the manufacture of pellets of
high permeability.
The device may only be used for this purpose.
(10) Plunger
(11) Die
(12) Bottom tool
(14) Allen key
size 5
(15) Allen key
size 4
(16) Socket spanner,
size
15
(13) Oil dipstick
