Seite 19
TABLET PRESS
13. Place the closed pressure tool on the pressure cylinder piston (6)
pressure plate (6a) again.
14. Press it onto the pressing tool plunger (10) using the spindle (4). Press the
Pellet pellet out of the die (11) into the bottom tool receptacle (12)
provided for this purpose.
15. Rotate the spindle (4) upwards.
16. Remove the pressing tool, pull the plunger (10) out and raise the die (11) .
The Pellet pellet will be located in the bottom tool receptacle (12). It can
now be simply removed.
17. The new working cycle can begin.
CAUTION Crushing Danger!
Do not place your finger between the threaded spindle and
the pressing tool.
