Delptronics Thunderclap User Manual
Page 10
Thunderclap Kit Instructions V2
Page 10 of 11
Finished
That’s it. Your Thunderclap is complete. Congratulations!
Pictures
This is what the assembled Eurorack module looks like. In this picture, each button and jack uses a different color
wire to make it stand out. The ground wires are all black.
This is what an assembled stompbox looks like inside. Yours might look different depending on how you connect the
pots. Notice that we have inserted a piece of cardboard between the PCB and the side of the enclosure so that the
bottom of the PCB does not touch the metal enclosure, which would cause a short circuit.
