DECALS
TRACTOR - - MODEL NUMBER 917.271110
KEY
PART
KEY
PART
NO.
NO.
DESCRIPTION
NO.
NO.
DESCRIPTION
1
156368
Decal, Oper. Instr.
10
156439
Decal, Fender Danger
3
163200
Decal, Hood, R.H.
12
146046
Decal, V-.Bett Drive Schematic
4
163202
Decal, Hood, L.H.
14
160396
Decal, V-Belt Schematic
5
163207
Decal, Fender Sd White
20
149516
Decal Battery Dngr/Psn Eng
Rad/^42*
21
138047
Decal, Battery Diehard Sears
6
133644
Decal, Customer Maintenance
--
138311
Decal, Lift Handle
7
163263
Decal, Dash Pnl Kohler 16.5
..
154515
Pad Footrest LH STLT
Ohv
- -
154516
Pad Footrest RH STLT
8
163203
Decal, Deck EZ3/Mulch Srs
- .
163484
Owner's Manual, English
9
163204
Decal, Fender, Craftsman
--
163485
Owner's Manual, Spanish
WHEELS & TIRES
KEY PART
NO. NO.
DESCRIPTION
1
59192
Cap \^e Tire
2
65139
Stem Value
3
106222X
Tire Front
4
59904
Tube Front Tire (Not Piovided,
Service Item Only
5
106732X427 Film Front
6 278H
Rtting Grease (Front Wheel
Only)
7
9040H
Beating Flange (Front Wheel
Only)
8
106108X427 Rbn Rear
9
122082X
Tire Rear
10
7152J
Tube RearTire (Not Provided,
Serde Item Only
11
104757X
Cap Axle
- - 144334 Sealant, Tire (10 oz. tube)
