TRACTOR - - MODEL NUMBER 917.271130
ENGINE
KEY
NO. PART
NO.
DESCRIPTION
1 162152 Control Throt 1 Ch
2 17720410 Screw Hex Thd Cut 1/4-20x5/8 T
3 Engine (S ob
Breakdown) Kohler Model No. CV16s-43520
4 159420 Muffler
13 12-041-03 Gasket
14 13280328 Nipple, Pipe 3/8 NPTx 3-1/2
15 13200300 Elbow, Std 90 Degree 3/8-18 Npt
16 STD551231 Washer
23 169837 Shield, BRN/DBR Guard
29 137180 Arrestor, Spark
31 109202X Tank, Fuel
32 158990 Cap Assembly, Fuel Tank, Vented
33 123487X Clamp Hose BIk
37 137040 Line Fuel
38 Plug Oil Drain (See Engine Breakdown)
40 124028X Bushing, Snap, Fuel Line
44 17490412 Screw, Hex Washer Head, Thd. Roll 1/4-20 x 3/4
45 17000612 Screw Hexwsh Thdr 3^-16 x 3/4
46 19091416 Washer, 9/32 x 7/8 x 16 Guage
62 S7D551131 Washer, Lock
77 19101216 Washer 5/16x3/4x16 Guage
79 M74O1O0O25 Bolt, Hex
80 74760508 Bolt, Hex Hd 5/16-18 Unc X 1/2
81 73510400 Nut, Keps Hex 1/4-20 Unc
101 M73030800 Nut Flange MB-1.25
NOTE: All component dimensions given In U.S. inches
1 inch s 25.4 mm
41
