SCHEMATIC
TRACTOR - - MODEL NUMBER 917.259561
RED
+
-O
a-
BLACK
BATTERY
AMMETER
(OPTIONAL)
RED
WHITE
IGNITION SWITCH
POSITION
CIRCUIT
“MAKE”
OFF
G + M + L
NONE
RUN/LIGHT
B+ L
A + Y
RUN
B + L
NONE
START
B+ L + S
NONE
ÖA_i>
O ! ! a
d
J
l
_Q
CLUTCH / BRAKE
(PEDAL UP)
o
RED
■c<5>
STARTER
BLACK
SOLENOID
WHITE
SEAT SWITCH
(NOT OCCUPIED)
BLACK
HOUR
METER
optional
T
:>
ATTMENT CLUTCH
(CLUTCH OFF)
GROUNDING
CONNECTOR
BLACK
c
IGNITION
UNIT
SPARK
gap
9
(2 PLUGS ON
TWIN CYL. ENGINES)
FUEL SHUT-OFF^
SOLENOID
CHARGINQ SYSTEM OUTPUT
16
AMPDC a aeooRPM
REGULATOR
NOTE
YOUR TRACTOR IS
EQUIPPED WITH A SPECIAL
ALTERNATOR SYSTEM.
THE LIGHTS ARE NOT
CONNECTED TO THE
BATTERY, BUT HAVE THEIR
OWN ELECTRICAL SOURCE.
BECAUSE OF THIS, THE
BRIGHTNESS OF THE LIGHTS
WILL CHANGE WITH ENGINE
SPEED. AT IDLE THE LIGHTS
WILL DIM. AS THE ENGINE IS
SPEEDED UP, THE LIGHTS
WILL BECOME THEIR BRIGHTEST.
30 VOLTS AC e 3600 RPM
(REGULATOR DISCONNECTED)
BROWN
BLACK.
L0J
HEADLIGHTS
NON-REMOVABLE
CONNECTIONS
“O—
rt
REMOVABLE
CONNECTIONS
WIRING INSULATED CLIPS
NOTE: IF WIRING INSULATED CUPS WERE REMOVED FOR
SERVICING OF UNIT, THEY SHOULD BE REPLACED TO
PROPERLY SECURE YOUR WIRING.
