Sears Craftsman 4.5 H.P. Engine Model No. 143.004500
For Yard Vacuum Model 247.770100
Ref.
No.
Part No.
Part Description
1.
37266
Cylinder
2.
26727
Dowel Pin
6.
33734
Breather Element
7.
37247
Breather Ass’y
12A.
36558
Breather Cover & Tube
14.
28277
Washer
15.
30589
Governor Rod
16.
34839A
Governor Lever
17.
31335
Governor Lever Clamp
18.
651018
Torx Screw 8-32 x 19/64”
19.
36281
Extension Spring
20.
32600
Oil Seal
30.
37527
Crankshaft
40.
40027
Piston, Pin & Ring Set (Std)
40028
Piston, Pin & Ring Set (.010” OS)
41.
40025
Piston & Pin Ass’y (Std)
40026
Piston & Pin Ass’y (.010” OS)
42.
40006
Ring Set (Std)
40007
Ring Set (.010” OS)
43.
20381
Piston Pin Retaining Ring
45.
36777
Connecting Rod Ass’y
46.
32610A
Connecting Rod Bolt
48.
27241
Valve Lifter
50.
37460
Camshaft
52.
29914
Oil Pump Ass’y
69.
35261
Mounting Flange Gasket
70.
36249B
Mounting Flange
72.
30572
Oil Drain Plug
72A.
28534
Oil Drain Plug
73.
28833
Drain Plug Gasket
75.
27897
Oil Seal
80.
30574A
Governor Shaft
81.
30590A
Washer
82.
30591
Governor Gear Ass’y
83.
30588A
Governor Spool
86.
650488
Screw 1/4-20 x 1-1/4
89.
611004
Flywheel Key
90.
611112
Flywheel
92.
650815
Bell Washer
93.
650816
Flywheel Nut
100.
34443B
Solid State Ignition
101.
610118
Spark Plug Cover
103.
651007
Torx Screw 10-24 x 15/16”
104.
37480
Cam Bushing
110.
37574
Ground Wire
110A.
37331
Ground Wire
119.
36787
Cylinder Head Gasket
120.
36825
Cylinder Head
125.
37288
Exhaust Valve
126.
37289
Intake Valve
130.
6021A
Screw 5/16-18 x 1-1/2”
135.
35395
Resistor Spark Plug
150.
31672
Valve Spring
151.
31673
Valve Spring Cap
151A.
40017
Intake Valve Seal
169.
36783
Valve Cover Gasket
172.
36784
Valve Cover
174.
30200
Screw 10-24 x 9/16”
178.
29752
Nut & Lock Washer 1/4-28
179.
30593
Retainer Clip
182.
6201
Screw 1/4-28 x 7/8”
184.
26756
Carburetor To Intake Pipe Gasket
185.
36785
Intake Pipe
186.
34337
Governor Link
200.
32264A
Control Bracket
203.
31342
Compression Spring
204.
651029
Torx Screw 5-40 x 7/16”
206.
610973
Terminal
207.
34336
Throttle Link
209.
30200
Screw 10-24 x 9/16”
215.
32410
Control Knob
223.
650451
Screw 1/4-20 x 1”
224.
36786
Intake Pipe Gasket
238.
650806
Screw 10-32 x 1/2”
239.
34338
Air Cleaner Gasket
240.
37115
Air Cleaner Body
245.
37116
Air Cleaner Filter
245A.
37117
Pre-Air Cleaner Filter
250.
37118
Air Cleaner Cover
260.
37151
Blower Housing
261.
30200
Screw 10-24 x 9/16”
262.
650831
Screw 1/4-20 x 1/2”
275.
36790A
Muffler
277.
650988
Screw 1/4-20 x 2-5/16”
279.
650737
Screw 1/4-20 x 1/2”
279A.
650902
Screw 10-32 x 7/16”
280.
37171A
Heat Shield
285.
35000A
Starter Cup
287.
650926
Screw 8-32 x 21-64”
290.
34357
Fuel Line
292.
26460
Fuel Line Clamp
300.
35586
Fuel Tank
301.
36246
Fuel Cap
305.
35577
Oil Fill Tube
306.
36996
O-Ring
307.
35499
O-Ring
309.
650562
Screw 10-32 x 1/2”
310.
35578
Dipstick
313.
34080
Spacer
324.
33177
Terminal
370A.
36261
Lubrication Label
370K.
36695
Starter Label
370R.
37317
Warning Label
370S.
37590
Instruction / Primer Label
380.
640278
Carburetor
390.
590737
Rewind Starter
400.
36792B
Gasket Set
416.
36085
Spark Arrestor
417.
650821
Screw 10-32 x 1/2”
900.
750856A
Short Block
Ref.
No.
Part No.
Part Description
