3 Installation Instructions
Operating Instructions
The battery operated acre counter operates in
one of two modes. In sleep mode, the display is
blank, and the counter is accumulating acres.
Sleep mode will be entered if a button is not
pressed for 20 seconds. In entry mode, the dis-
play is on, and the operator can enter values. To
get into entry mode, press the FUNC button. If you
continue to press the FUNC button, the acre
counter will cycle through the functions that it can
perform. The icons above the digits indicate which
function is selected. The available functions are:
• Field Acres
• Total Acres
• Pulses per Mile
• Width
• Password
Field Acres
Refer to Figure 3
Press the FUNC button until the "FIELD" icon ap-
pears in the display. The digits indicate the acres
covered since the field acre counter was cleared.
To clear the field acre count, depress the UP and
DOWN buttons for 2 seconds.
Field acres will count in tenths of an acre up to
9999.9 acres.
Total Acres
Refer to Figure 4
Press the FUNC button until the "TOTAL" icon ap-
pears in the display. The digits indicate the acres
covered since the total acre counter was cleared.
To clear the total acre count, press and hold the
UP and DOWN buttons for 2 seconds. If a pass-
word has been entered you will not be able to
clear the total acre count.
Total acres will count from 1 to 99999 acres.
FLD
ACRES
TOT
ACRES
Figure 3
Figure 4
