Great Plains YP Martin Row Cleaner - Manual (Page 10)

207-183M 4/17/2006
8
Double Arm Row Cleaner
NOTE: Double Arm Row Cleaner will not fit on
Twin Row applications.
For 30” Row Spacings - Order and install either
YP1225 or YP1625 Martin Double Arm Row
Cleaner and Mount. One kit will cover entire
planter.
Refer to Figure 6
1. Remove both 1/2-13 x 1 3/4 bolts and 1/2-13 lock
nuts from right-hand and left-hand double arm
row cleaners.
2. Attach a left-hand double arm row cleaner (1) or
a right-hand double arm row cleaner to mounting
plate (3). NOTE: Attach a left-hand arm row
cleaner to an opener with a left-hand coulter.
Attach a right-hand arm row cleaner to an
opener with a right-hand coulter.
3. Secure row cleaner (1) to mounting plate (3) us-
ing bolts (2) and lock nuts removed in step 1.
NOTE: Make sure bolts are inserted from outside
in.
4. Repeat steps for all openers.
Figure 6
Double Arm Installation
24404
