Introduction
Verifying Flow Rate Limits
The flow rate of spray must be within the specified range for the flow meter being used.
Note:
Only Krohne Magmeters sold through Raven Industries should be used with Raven controllers. No
other Krohne Magmeters are supported.
Flow Meter Model Flow Range
RFM 5 0.1 - 5 GPM [0.2 - 18.9 lit/min]
RFM 15 0.3 - 15 GPM [1.1 - 56.8 lit/min]
RFM 60P 1 - 60 GPM [3.8 - 210 lit/min]
RFM 60S 1 - 60 GPM [3.8 - 210 lit/min]
RFM 100 5 - 100 GPM [18.9 - 380 lit/min]
RFM 200/200 Poly 15 - 200 GPM [56.8 - 760 lit/min]
Magmeter 200 3 - 200 GPM [11.36 - 757 lit/min]
RFM 400 25 - 400 GPM [94.6 - 1515 lit/min]
Krohne 3” Magmeter* 15 - 250 GPM [56.78 - 946.25 lit/min]
Krohne 4” Magmeter* 35 - 1,800 GPM [132.48 - 6813 lit/min]
Krohne 6” Magmeter* 70 - 3,000 GPM [264.95 - 11,355 lit/min]
