User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 17” LCD Panel
Pixel pitch 0.255mm(H) x0.255mm(V)
H-Frequency
24KHz –80KHz
Video
V-Frequency 55Hz– 75Hz
Display Colors 16.2M Colors
Max. Resolution 1440 x 900 @75Hz
Plug & Play VESA DDC2B TM
ON Mode ”36W
Power Saving Mode ”2W EPA ENERGY STAR ®
OFF Mode ”1W
Input Terminal
VGA
DVI-D (optional)
Maximum Screen Size
Hor. : 367.2.mm
Ver. : 229.5mm
Power Source 100~240VAC±10%,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 5° to 35°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
Dimensions
405(W)×3
72(H)×199(D) mm
15.9”(W)×1
4.6”(H)×7.8”(D)
Weight (NW) 3.
0kg (6.6 lb)
***The above specification is subject to actual product specification and is subject to change without
prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can refer to
www.hannsg.com FAQ section.
20
