User’s Manual
19
ERROR MESSAGE & POSSIBLE SOLUTIONS

CABLE NOT CONNECTED:
1. Check that the signal-cable is properly connected, If the connector is loose, tighten the
connector’s screws.
2. Check the signal-cable’s connection pins for damage.
 INPUT NOT SUPPORT :
Your computer has been set to unsuitable display mode, set the computer to display mode given
in the following table.
FACTORY PRESET TIMING TABLE:
(VGA AND DVI INPUTS)
MODE RESOLUTION
HORIZONTAL
FREQUENCY (KHz)
VERTICAL
FREQUENCY (Hz)
1 640×480 @60Hz 31.469 59.941
2 640×480 @67Hz 35.000 66.660
3 640×480 @72Hz 37.861 72.809
4 640×480 @75Hz 37.500 75.000
5 720×400 @70Hz 31.469 70.087
6 800×600 @56Hz 35.156 56.250
7 800×600 @60Hz 37.879 60.317
8 800×600 @72Hz 48.077 72.188
9 800×600 @75Hz 46.875 75.000
10 832×624 @75Hz 49.722 74.550
11 1024×768 @60Hz 48.363 60.004
12 1024×768 @70Hz 56.476 70.069
13 1024×768 @75Hz 60.023 75.029
14 1152×870 @75Hz 68.681 75.062
15 1152×864 @75Hz 67.500 75.000
16 1280×720 @60Hz 44.955 59.940
17 1280×800 @60Hz 49.702 59.810
18 1280×960 @60Hz 60.000 60.000
19 1280×1024 @60Hz 63.981 60.020
20 1280×1024 @75Hz 79.976 75.025
21 1360×768 @60Hz 47.712 60.015
22 1440×900 @60Hz 55.935 59.887
23 1440×900 @75Hz 70.635 75.000
24 1680×1050 @60Hz 65.290 59.954
25 1600×1200 @60Hz 75.000 60.000
26 1920×1080 @60Hz 67.500 60.000
27 1920×1080 @60Hz 66.587 59.934
