3200 Timer Assembly
.
1.................... 1..................... 13870................... Housing, Timer, 3200
.
2.................... 1..................... 13011................... Arm, Cycle Actuator
.
3.................... 1..................... 40096-24.............. Dial 12AM Regen Assy, Black
40096-02.............. Dial 2AM Regen Assy, Black
.
4.................... 1..................... 13886................... Knob, 3200
.
5.................... 5..................... 13296................... Screw, Hex Wsh, 6-20 x 1/2
.
6.................... 1..................... 11999................... Label, Button
.
7.................... 1..................... 14381................... Skipper Wheel Assy, 12 Day
.
.
.
14860................... Skipper Wheel Assy, 7 Day
.
8.................... 1..................... 13014................... Pointer, Regeneration
.
9.................... 1..................... 14265................... Clip, Spring
.
10.................. 2..................... 13311................... Spring, Detent, Timer
.
11.................. 2..................... 13300................... Ball, 1/4” SS
.
12.................. 1..................... 15424................... Spring, Detent, Timer
.
13.................. 1..................... 13911................... Gear, Main Drive, Timer
.
14.................. 1..................... 19210................... Program Wheel Assy, 3200
.
15.................. 21................... 15493................... Pin, Spring, 1/16 x 5/8 SS
.
16.................. 1..................... 13018................... Pinion, Idler
.
17.................. 1..................... 13312................... Spring, Idler Shaft
.
18.................. 1..................... 13017................... Gear, Idler
.
19.................. 1..................... 13164................... Gear, Drive
.
20.................. 1..................... 13887................... Plate, Motor Mounting
.
21.................. 1..................... 18743-1................ Motor, 120V, 60Hz 1/30 RPM, 5600
19659-1................ Motor, 24V, 60 Hz 1/30 RPM
.
22.................. 2..................... 13278................... Screw, Phil Hd Mach, 6-32 x 1/8
.
23.................. 3..................... 11384................... Screw, Phil, 6-32 x 1/4 Zinc
.
24.................. 1..................... 13881................... Bracket, Hinge Timer
.
25.................. 3..................... 14087................... Insulator
.
26.................. 1..................... 10896................... Switch, Micro
.
27.................. 1..................... 15320................... Switch, Micro, Timer
.
28.................. 2..................... 11413................... Screw, Pan Hd Mach, 4-40 x 1 1/8
.
29.................. 1..................... 14007................... Label, Time of Day
.
30.................. 1..................... 14045................... Label, Instruction
.
31.................. 1..................... 13864................... Ring, Skipper Wheel
.
32.................. 1..................... 15066................... Ball, 1/4” Delrin
Not Shown.... 1..................... 13902................... Harness, 3200
Not Shown.... 2..................... 40422................... Nut, Wire, Tan
Not Shown.... 1..................... 15354-01.............. Wire, Ground 4”
For Service Assembly Numbers, See the Back of this Manual
