TOURnado™ IP EXA User Manual Rev. A © Copyright 2014 Blizzard Lighting, LLC
2. MEET THE TOURNADO™ IP EXA LED PAR
CONTROL FEATURES
• RGBAW+UV color mixing via 12x 15W 6-in-1 LEDs
• LED control panel with 4 touch sensitive electronic buttons
• Super-sharp 25° beam angle
• Variable electronic dimming & strobe
• Built-in color & chase macros via DMX
• Built-in automated programs via master/slave
• RGBAW+UV color mixing ability in standalone mode
• RGBAW+UV (6-Ch), RGBAW+UV & Strobe (7-Ch), Dim, RGBAW+UV
& Strobe (8-Ch), & Extended w/32-bit dimming (11-Ch) DMX Profiles
ADDITIONAL FEATURES
• Rugged and well-built (It hits the gym regularly)
• Convection cooled cast aluminum housing
• Dual mounting brackets for positioning flexibility
• Flicker-free constant-current 500MA LED driver
• IP rated locking power and 3-pin DMX connections
DMX Quick Reference - 11 / 8 Channel Mode
Channel 11 Channel 8 Channel
1 Dimmer Dimmer
2 Red Intensity Red Intensity
3 Green Intensity Green Intensity
4 Blue Intensity Blue Intensity
5 Amber Intensity Amber Intensity
6 White Intensity White Intensity
7 UV Intensity UV Intensity
8 Strobe Strobe
9 Static Colors + Auto ---
10 Built-in Programs ---
11 32-bit Dimming ---
DMX Quick Reference - 7 / 6 Channel Mode
Channel 7 Channel 6 Channel
1 Red Intensity Red Intensity
2 Green Intensity Green Intensity
3 Blue Intensity Blue Intensity
4 Amber Intensity Amber Intensity
5 White Intensity White Intensity
6 UV Intensity UV Intensity
7 Strobe ---
