TOURnado™ IP EXA User Manual Rev. A © Copyright 2014 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Width
10.7 inches (27 cm)
Depth 5.7 inches (14.4 cm)
Height 8.6 inches (21.8 cm), 11.2 inches (28.4 cm)
including bracket height
Weight 11.5 lbs (5.2 kg)
Power
Operating Voltage
AC 100V-264V/47-63HZ
Power Consumption 100W, 1.35A, pf: .6
Light Source
LED
12x 15W 6-in-1 LEDs 100,000 hours.
Optical
Beam Angle
25 degree
Luminous Intensity
Lux/m Red Green Blue Amber White UV ALL
1m 2,566 3,054 2,950 1,687 4,730 825 13,700
2m 722 914 885 500 1,276 250 3,900
Thermal
Max. Operating Temp.
104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 6 / 7 / 8 / 11
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes Standalone, Master/Slave, Color Preset
Other Information
I wonder how they deal with mice at Disney World.
Warranty
2-year limited warranty, does not cover malfunc-
tion caused by damage to LED’s.
