ROCKLITE Quadra Manual Rev. B Copyright (c) 2011 Blizzard Lighting, LLC
2. MEET THE ROCKLITE™ Quadra LED PAR
CONTROL FEATURES
• Astounding RGBW color mixing via 18x 8W Red/Green/Blue/White
“4-in-1” LEDs
• Variable electronic strobe & strobe
• Built-in color & chase macros via DMX
• Built-in automated programs via master/slave
• Built-in sound active programs
• RGBW color mixing ability in standalone mode
• HSV (3-Ch), RGBW (4-Ch), RGBW + Dimmer (5-Ch) & Extended (8-
Ch) DMX Profiles
ADDITIONAL FEATURES
• Rugged and well-built (It hits the gym regularly)
• Light source: 18x 8-watt 4-in-1 LEDs
• Super-quiet variable-speed internal Fan Cooling
• Dual mounting brackets for positioning flexibility
• Flicker-free constant-current 400hz LED driver
DMX Quick Reference - 8 / 9 Channel Mode
Channel 8 Channel 9 Channel
1 Dimmer Dimmer
2 Red Intensity Red Intensity
3 Green Intensity Green Intensity
4 Blue Intensity Blue Intensity
5 White Intensity White Intensity
6 Strobe Strobe
7 Built-in Programs Built-in Programs
8 Program Speed Program Speed
9 --- 32-Bit Dimmer
DMX Quick Reference - 3 (HSV) / 4 / 5 Channel Mode
Channel HSV 4 Channel 5 Channel
1 Hue Red Intensity Red Intensity
2 Saturation Green Intensity Green Intensity
3 Value Blue Intensity Blue Intensity
4 --- White Intensity White Intensity
5 --- --- Dimmer
