ROCKLITE Quadra Manual Rev. B Copyright (c) 2011 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length
10 inches (254 mm)
Width 7.75 inches (197 mm)
Height 7.75 inches (197 mm)
Weight 5.25 lbs (2.4 kg)
Power
Operating Voltage
90-230VAC, 50-60 Hertz
Fuse 3A 250V
Power Consumption 140W
Light Source
LED
18x 8W 4-in-1 LEDs 100,000 hours.
Optical
Beam Angle
25 degree optics standard
26 degree beam
30 degree field
Luminous Intensity 10,220 Lux @ 1m (25 degree optics)
Thermal
Max. Operating Temp.
104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 3 / 4 / 5 / 8 / 9
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating Modes
Standalone, Master/Slave, Sound Active,
Color Preset
Coolness Factor
Leventy Billion Percent
Warranty
2-year limited warranty, does not cover mal-
function caused by damage to LED’s.
