ROCKLITE AW Manual Rev. B © 2010-14 Blizzard Lighting, LLC
DMX Values In-Depth (8-Channel Mode)
Channel Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Amber Segment #1 (0% <--> 100%)
3 000 <--> 255 White Segment #1 (0% <--> 100%)
4 000 <--> 255 White Segment #2 (0% <--> 100%)
5 000 <--> 255 Amber Segment #2 (0% <--> 100%)
6
000 <--> 255
Strobe
Strobe (Slow <--> Fast)
7 000 <-> 255 Program Speed/Function (Slow <--> Fast)
8
000 <-> 049
050 <-> 200
201 <-> 250
251 <-> 255
Built-In Programs
Channels 1-5 are active
8-Bit Color Mixing
Built-In Programs (Ch-7 controls speed)
Sound Active Mode
DMX Values In-Depth (4-Channel Mode)
Ch. Value What It Does (4 Ch.)
1 000 <--> 255 Amber Segment #1 (0% <--> 100%)
2 000 <--> 255 White Segment #1 (0% <--> 100%)
3 000 <--> 255 White Segment #2 (0% <--> 100%)
4 000 <--> 255 Amber Segment #2 (0% <--> 100%)
