ROCKLITE AW Manual Rev. A

SAFETY INSTRUCTIONS

• Please keep this User Guide for future use. If you sell the unit to someone

else, be sure that they also receive this User Guide.

• ALWAYS make sure that you are connecting to the proper voltage, and that

the line voltage you are connecting to is not higher than that stated on the de-

cal or rear panel of the fi xture.

• This product is intended for indoor use only.

• To prevent risk of fi re or shock, do not expose fi xture to rain or moisture.

• Make sure there are no fl ammable materials close to the unit while operating.

• The unit must be installed in a location with adequate ventilation, at least

20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are

blocked.

• ALWAYS disconnect from the power source before servicing or replacing fuse

and be sure to replace with same fuse size and type.

• ALWAYS secure fi xture using a safety chain. NEVER carry the fi xture by its

cord. Use its carrying handles.

• DO NOT operate at ambient temperatures higher than 104°F (40°C).

• In the event of a serious operating problem, stop using the unit immediately.

NEVER try to repair the unit by yourself. Repairs carried out by unskilled people

can lead to damage or malfunction. Please contact the nearest authorized tech-

nical assistance center. Always use the same type spare parts.

• NEVER connect the device to a dimmer pack.

• Make sure the power cord is never crimped or damaged.

• Never disconnect the power cord by pulling or tugging on the cord.

• Avoid direct eye exposure to the light source while it is on.

Caution! There are no user serviceable parts inside the unit. Do not

open the housing or attempt any repairs yourself. In the unlikely event

your unit may require service, please contact Blizzard Lighting at sup-

[email protected].

Page 17

ROCKLITE AW Manual Rev. A

Tech Specs!

Weight & Dimensions
Length

10 inches (254 mm)

Width

7.75 inches (197 mm)

Height

7.75 inches (197 mm)

Weight

5.25 lbs (2.4 kg)

Power
Operating Voltage

90-230VAC, 50-60 Hertz

Fuse

3A 250V

Power Consumption

120W

Light Source
LED

36x 3W AW LEDs 60,000 hours. (24 White,

12 Amber)

Optical
Beam Angle

25 degree optics standard

26 degree beam

30 degree fi eld

Luminous Intensity

19,100 Lux @ 1m (25 degree optics)

Thermal
Max. Operating Temp.

104 degrees F (40 degrees C) ambient

Control
Protocol

USITT DMX-512

DMX Channels

2 or 8 (Selectable)

Input

3-pin XLR Male

Output

3-pin XLR Female

Other Operating Modes

Standalone, Master/Slave, Sound Active,

Color Preset

Angle of The Dangle
Inversely proportional to the heat of the beat

Warranty

2-year limited warranty, does not cover mal-

function caused by damage to LED’s.
