ProPar Quadra LED Manual Rev. A Copyright (c) 2010 Blizzard Lighting, LLC
2. MEET THE ProPar™ Quadra LED PAR
CONTROL FEATURES
• RGBW color mixing via 12 high power 8W 4-in-1 LEDs
• Variable electronic strobe
• Variable electronic dimmer
• Built-in color & chase macros via DMX
• Built-in automated programs via master/slave
• Built-in sound active programs
• RGBW color mixing ability in standalone mode
• Intuitive LCD control panel for ease of programming
ADDITIONAL FEATURES
• Rugged and well-built (It hits the gym regularly)
• Light source: 12x 8-watt Edison 4-in-1 LEDs
• Quiet Internal Fan Cooling
• Dual mounting brackets for positioning fl exibility
• Color mixing without compare thanks to revolutionary 4-in-1 technol-
ogy
DMX Quick Reference
Channel What It Does
1 Dimmer
2 Strobe
3 Red Intensity
4 Green Intensity
5 Blue Intensity
6 White Intensity
7 Color Macros
8 Program Speed (#8) Slow <-->
Fast
Page 6
ProPar Quarda LED Manual Rev. A Copyright (c) 2010 Blizzard Lighting, LLC
Figure 1: The ProPar™ Pin-Up Picture
Revolutionary
4-in-1 LEDs
Cast Aluminum
Enclosure
Mounting Yoke &
Adjustment/Lock-
ing Knobs
Figure 2: The Rear Connections
AC Power/
Fuse
DMX In DMX Out LCD Control Panel
DMX/
Sound
Indicator
LEDs
Integral Gel
Frame
