Operating features – Wood’s Powr-Grip P11104DCO User Manual
Page 7
Rev 13.0/6-13
5
P1-DCO-DVS: #35112
OPERATING FEATURES
Note: Components featured in the following instructions for assembling, operating or
maintaining the vacuum lifter are underlined on their first appearance in each section.
P11104DC shown.
1 LIFT BAIL
2 LIFT BAR
3 VACUUM PAD
4 BATTERY
5 Enclosure with VACUUM PUMP
and VACUUM SWITCHES
6 BATTERY TEST BUTTON
7 LOW VACUUM WARNING LIGHT
8 VACUUM GAUGES
9 CONTROL HANDLES
10 AIR FILTERS
11 VALVE HANDLE
12 BATTERY GAUGE
13 ROTATION RELEASE LEVER
14 BATTERY CHARGER
15 TILT RELEASE LEVER
16 VACUUM RESERVE TANKS
17 PAD CHANNEL
18 LOW VACUUM WARNING BUZZER
