INSTALLATION INSTRUCTIONS FOR SIRIUS 2
MODEL 3570M-A
HALOGEN MAGNET MOUNT
Your choice of a Wolo warning light is the perfect choice to compliment your vehicle. Sirius is manufactured
with the finest materials. Each light is tested to meet our high standards before it is packaged, so to assure a
perfect working light. Our quality workmanship and components are Wolo’s assurance of a product that will
give years of dependable service.
If you need help using your new Wolo warning lights, our technicians are available to answer your questions,
Monday thru Friday, from 9 AM to 4 PM EST at 1-888-550-4676.
IMPORTANT: The vehicle should never be driven with this warning light magnetically mounted. It is possible
that the light could dislodge off the mounting surface and cause damage, injury, or death. Ignoring this warn-
ing shall be the sole responsibility of the user and or vehicle owner.
MAGNET MOUNT
1. The magnets’ holding power to the mounting surface is dependent upon the following: flatness, condition
and finish as well as the thickness of steel surface. For maximum magnet strength, follow these recom-
mendations:
A. The vehicle’s mounting surface should be kept clean and free of wax, dirt, dust and foreign particles.
B. The bottom of the magnets rubber cover should be kept clean and free of wax, dirt, dust and foreign
particles.
C. Always make sure that the mounting surface is flat and that all four (4) magnets are fully secured to the
mounting surface.
D. Never attempt to secure magnet mount to a vehicle that has fabric or vinyl covering the mounting sur-
face.
2. Locate the desired location where you
wish to mount the warning light. For best
results you should make sure the lens is
unobstructed so that the light can be seen
360 degrees.
POWERING WARNING LIGHT:
3. To turn on the warning light, simply
insert the cigarette lighter plug into the
vehicles power outlet.
4. Press the on/off button on the back on the cigarette lighter plug. When the light is operating the LED on
the plug’s switch will illuminate.
5. To turn off the warning light, remove the cigarette lighter plug from the vehicle’s power socket or position
the on/off switch to off. IMPORTANT: The cigarette lighter plug has a built-in fuse to protect the warning
light and the vehicle. If the warning light does not turn on when the plug is inserted into the vehicle power
socket, check the fuse built into the power plug by the following method: The tip of the power plug has a
chrome push-in contact which is secured by a black nut. Unscrew the nut which will give you access to
the light’s fuse. If the fuse needs to be replaced, use a 10-amp fuse. Follow the reverse procedure to re-
assemble fuse back into power-plug. (See Fig. 1)
REPLACING BULB
WARNING: A serious injury can result if the bulb is touched when hot.
Always allow five (5) minutes for the bulb to cool before removing. Always
wear gloves and eye protection when removing the bulb because Halogen
bulbs are pressurized and if broken, glass can be projected.
6. Remove the six screws located at the bottom of the light (one in each
corner and one in the middle each side) holding the lens to the lights
base and remove lens. (See Fig. 2)
7. Replacement bulb type: use only halogen 796 / 35watt halogen, 12 volt.
Current draw: 2.73 amps.
Fig. 1
Fig. 2
Fuse 10 AMP
Contact
Nut
On/Off
Switch
