12 en | On-Screen Display Menu Navigation AutoDome Modular Camera System
F01U064036 | 1.1 | 2007.01 VG4-200, VG4-300, VG4-500i Series User’s Manual Bosch Security Systems, Inc.
2.4 PTZ Setup Menu
The PTZ Menu provides access to pan/tilt/zoom settings that can be changed or customized.
Menu items with an * are the default settings.
PTZ Menu Choices:
PTZ Setup
Exit...
* Autopan: 30 deg/sec
* Tour 1 Period: 5 sec
* Tour 2 Period: 5 sec
* PTZ Fixed Speed: 4
* Inactivity: OFF
* Inact. Period 2 min
* AutoPivot: ON
* AutoDome Orientation NORMAL
* Freeze Frame on Prepostion ON
Tilt Up Limit...
Restore Defaults
* = Factory Setting
Focus / Iris: Select
Menu Description Sub-menu / Description Default
Setting
Exit Exits the menu.
AutoPan Adjusts speed of camera during
AutoPan and AutoScan. Sliding scale: – (1º/sec. to 60º/sec.) + 30º/sec.
Tour 1 Period Changes dwell time between
presets during the tour. Sliding scale: – (3 sec. to 10 min.) + 5 sec.
Tour 2 Period
(not available with
200 Series models) Changes dwell time between
presets during the tour. Sliding scale: – (3 sec. to 10 min.) + 5 sec.
PTZ Fixed Speed Sets pan and tilt speed when
controlled by a fixed speed
controller. Sliding scale: – (1 to 15) + 4
Inactivity Selects the mode that an
AutoDome reverts to after the
period of inactivity set in the
inactivity period. Scene 1: Returns to Preset 1.
Prev Aux: Returns to previous activity,
such as Aux commands 1, 2, 7, 8, 50, or
52.
OFF: Remains on the current scene indefi-
nitely. OFF
Inactivity Period Sets the time period of inactiv-
ity before the above action
occurs. Sliding scale: – (3 sec. to 10 min.) + 2 min.
AutoPivot Automatically rotates the cam-
era 180º when following a sub-
ject traveling directly beneath
the camera. OFF or ON ON
AutoDome
Orientation
(not available with
18x color camera) Automatically rotates the video
180º. INVERTED or NORMAL NORMAL
