Snow Switch ® Model LCD–8 Aerial Snow Controller, 100 – 240 VAC
24782 Rev. A 03/13 (800) 234-4239 http://www.networketi.com 13 of 14 Environmental Technology, Inc.
SPECIFICATIONS
General
Area of use Nonhazardous locations
Approvals
109R
Type 873
Temperature Regulating Equipment
Enclosure
Protection NEMA 3R
Cover attachment Polycarbonate with machine screws
Entries 1 x 3/4" entry (bottom)
Material Polycarbonate
Mounting Pole mount
Dimensions 4.6" (W) x 6.1" (H) / 117mm (W) x 155mm (H)
Control
Supply voltage ETI PN 24619: 100VAC – 240VAC; 50/60 Hz
ETI PN 24781: 24VAC; 50/60 Hz
Load 3 amp maximum inductive
16 amp maximum resistive
Heater Hold-On timer 0, 1, 3 (default) or 5 hours; configured by magnetic reed switch
Set point temperature Off (moisture only), 36°F, 38°F (default), 40°F;
configured by magnetic reed switch
Interface
Status indicators SUPPLY (green): Power on; will flash while in configuration mode
HEAT (yellow): Heating cycle in progress
Wire and Cable Ratings
Power cable Size for heater load (16 amps maximum)
Heater cable Size for maximum heater load
Environmental
Operating temperature –40°F to 104°F (–40°C to 40°C)
Storage temperature −67°F to 167°F (−55°C to 75°C)
Post –Installation LCD-8 Test
Most problems result from installation errors. Before testing, verify that unit is prop-
erly installed.
1. Connect power to snow melting system. Wait 15 seconds; system should
not actuate.
2. Using ice water or other cooling agent, cool ambient air temperature sensor
to below 38°F (3.3ºC); system should not actuate. Apply moisture to moisture
sensing grid. System should actuate in less than 15 seconds.
3. Dry moisture sensing grid. Disconnect power to snow melting system. Wait 1
minute, then reconnect power. If system actuates, ensure sensing grid is dry
and ambient air temperature is above 38°F (3.3°C), then repeat this step.
