VGA2-DA4 Installation Guide
8001 Terrace Ave.
Phone: 608-831-0880
Suite 201
Toll-Free: 866-462-8649
Middleton, WI 53562
Fax: 608-831-1833
Technical Specifications
I/O Connections
Input Connectors
1x HD-15 female, 1x 3.5mm TRS female
Video Signal Types
RGBHV, RGBS, RGsB, YPbPr
Maximum Resolution
2560x1600
RGB Level Range
0.5-2.0V p-p
Output Connectors
4x HD-15 female, 4x 3.5mm TRS female
Audio Bandwidth/Level
20Hz-20kHz @ 0.5-1V p-p
RGB Bandwidth
500+ MHz
DDC Capability
DDC1, DDC2, DDC2B
Chassis and Environmental
Dimensions (HxWxD)
1.7"x6.3"x2.3" (44x160x58mm)
Shipping Weight
1.8 lbs. (0.82 kg)
Operating Temperature
0° to +50° C (+32° to +122° F)
Operating Humidity
10% to 90%, Non-condensing
Storage Temperature
-10° to +60° C (+14° to +140° F)
Storage Humidity
10% to 90%, Non-condensing
Enclosure
Painted Steel
External Power Supply
5VDC @ 2.6A
Regulatory
CE, RoHS
Other
Warranty
2 years
What’s in the Box
VGA2-DA4, AC Power Supply, Installation Guide
