GCS1716 Overview
Port 1~16 Switch Button 1.
Reset Button 2.
USB Sharing Port* 3.
*Note: The USB sharing device can only be used if your computer is connected to the KVM via a USB
KVM Cable. Also, it does not support cascading; in other words, it can only be shared within the 16 ports
of the KVM
Front view
Firmware Upgrade Recovery Switch 4.
Firmware Upgrade Cable Port 5.
Power LED 6.
