❑ Illustrated Parts Breakdown
170
FoamLogix 3.3 / 5.0 / 6.5 Installer / Operations Manual
p/n: 029-0021-68-0
9
Plate Drawings
Description
Plate Number
FoamLogix System Packaging ................................................................................... 850B
Pump Motor Sub-Assembly........................................................................................ 844B
Foam Pump Sub-Assembly........................................................................................ 849A
FoamLogix with NO Tank Selector Option ................................................................. 848B
FoamLogix with “MST” Selector Option...................................................................... 847B
FoamLogix with MDT II Selector Option..................................................................... 846B
FoamLogix with ADT Option....................................................................................... 845B
Foam System Power Filter Kit Option ........................................................................ 891A
Cable Harness
Harness, Distribution Box, Single Tank Motor Control ............................................ 113434
Harness, Distribution Box, Dual Tank Motor Control............................................... 113435
Harness, FoanLogix Control Head .......................................................................... 113436
113437113438113439
