table
10
Pressure
t
able
LOW
SIDE
PRESSURE
+4 PSIG
HIGH S
IDE
P
RESSURE
+10
PSIG
Tables
based
upon
rated
CFM
(airflow)
across
the
evaporator
coil.
If incorrect charge suspected (more than
+4
psig
suction,
+
10
psig
liquid),
it
is
recommended
refrigerant
charge
be
reclaimed,
system
evacuated
and
charged
to
serial
plate
quantity
.
c
OO
lI
n
G
Air
Temperature Entering Outdoor Coil Degree F
Model
Return Air Temperature
Pressure
65°
70°
75°
80°
85°
90°
95°
100°
105°
110°
115°
120°
125°
PA1342
75° DB 62° WB
Low Side High Side
126 242
128 265
129 288
131 311
132 334
134 357
136 380
137 409
138 437
140 466
141 494
142 523
143 551
80° DB 67° WB
Low Side High Side
135 248
137 272
138 295
140 319
142 343
143 366
144 402
146 419
148 448
149 478
151 507
152 536
153 565
85° DB 72° WB
Low Side High Side
145 257
147 281
149 306
151 330
152 355
154 379
156 404
157 434
159 464
160 494
162 525
163 555
165 585
PA1348
75° DB 62° WB
Low Side High Side
125 239
127 263
128 287
129 311
130 335
132 359
133 383
134 410
136 438
137 465
139 492
140 520
142 547
80° DB 67° WB
Low Side High Side
134 245
135 270
137 294
138 319
139 344
141 368
142 404
144 421
145 449
147 477
148 505
150 533
152 561
85° DB 72° WB
Low Side High Side
144 254
145 279
147 305
148 330
150 356
151 381
153 407
154 436
156 465
158 494
160 523
161 552
163 581
PA1360
75° DB 62° WB
Low Side High Side
124 224
125 254
126 285
127 315
128 345
129 375
130 406
131 431
131 456
132 480
133 505
134 530
80° DB 67° WB
Low Side High Side
133 230
134 261
135 292
136 323
137 354
138 385
138 426
140 442
141 467
141 493
142 518
143 544
85° DB 72° WB
Low Side High Side
143 238
144 270
145 302
146 334
147 366
148 398
149 431
150 457
151 484
152 510
153 537
154 563
