1050P/1050eP Installation Space (continued)

12

15.3

(389)

62.2

(1580)

12.0(306)

93.3

(2369)

101.1

(2569)

31.8

(807)

3.9

(100)

35.2

(895)

15.7

(400)

10.5

(267)

4.6(117)

3.9

(100)

40.2

(1020)

48.5

(1231)

Main body + PF-701 + FD-503

Unit: inches (mm)

15.3

(389)

62.2

(1580)

178.1

(4523)

185.9

(4723)

31.8

(807)

3.9

(100)

35.2

(895)

3.9

(100)

40.2

(1020)

Main body + PF-701 + LS-501/LS-505 + SD-506 + FS-503

1170

21.4

(544)

9.3

(237)

3.4(85)

30.9

(785)

12.0(306)

Unit: inches (mm)

15.3

(389)

12.0(306)

165

(4190)

176.8

(4490)

31.8

(807)

3.9

(100)

35.2

(895)

29.1

(740)

30.9

(785)

22.2

(563)

15.7

(400)

7.9

(200)

48.5

(1231)

48.1

(1223)

Main body + PF-701 + FD-503 + LS-501/LS-505 + PB-502

62.2

(1580)

40.2

(1020)

Unit: inches (mm)
