ACTiSYS Corp.
IR Printer Adapter IR100M+/100M/100MP
SETUP
IR100M/IR100M+
DB25F Printer Port
CEN36F Port
IR Head
Figure 4: Connection Diagram with Passing Thru
IR100MP
CEN36F Port
IR Head
Figure 5: Connection Diagram without Passing Thru
Release 3.2, December 9, 2003
10
